OKI Error Code 370, 371, 373 - when paper jams occur

A paper jam has occurred around the duplex unit.

1. Take out the duplex unit (1) by pulling it upward while holding the center recess on the back of the machine.



2. Check for jammed paper inside the machine. If jammed paper remains, remove it.



   Memo

   • If paper is invisible, check the innermost part of the printer.
   • If the paper removed from the printer is shredded or torn, remove all paper fragments from inside the unit so that none are left inside.

3. Check for jammed paper in the duplex unit. If jammed paper remains, pull it out gently. Check the back side of the duplex unit and remove jammed paper gently if it remains.



4. Open the upper duplex unit cover (2) and check for jammed paper. If jammed paper remains, pull it out gently and close the cover.



Replace the duplex unit (1) into the machine.

Task is complete.
